(Gambar) Skuter YAMAHA EGO LC 125CC







(Gambar) Skuter YAMAHA EGO LC

Spec : Engine

Type Liquid-cooled 4-stroke, SOHC 2valve

Cylinders Forward-inclined single cylinder

Displacement 124.9 cm3

Bore x Stroke 52.4mm x 57.9mm

Compression Ratio 10.9:1

Maximum Horsepower 7.8kw @ 8000 rpm

Maximum Torque 10.0 N.m @ 7000 rpm

Starting System Electric start & kick starter

Lubrication System Wet sump

Engine oil capacity 0.9 L

Fuel tank capacity 4.1 L

Carburetion BS26

Ignition system C.D.I. (digital)

Transmission

Primary reduction ratio 2.625

Secondary reduction ratio 3.750

Gear ratios 2.540-0.838

Clutch type Dry, centrifugal automatic, Coil spring

Transmission V-belt automatic

Chasis

Frame Type Steel tube underbone

Overall Length 1,850mm

Overall Width 685mm

Overall Height 1,060 mm

Seat Height 750mm

Wheelbase 1,260 mm

Min. Ground Clearance 125mm

Weight (with oil and a full fuel tank) 104kg
